90300 Temperature Limit Control

Specs At A Glance

• Multiple sensor option (3) (Using individual and/or dual sensor assemblies)
• Sensor Redundancy (Higher temperature of two operating sensors used)
• Easy remote sense (Manual reset only if operating limit doesn’t open)
• Smart manual reset (Manual reset only if operating limit doesn’t open)
• Serviceman reset protection (Latch-up after three consecutive lockouts) Latch-up mode shuts down the control after three consecutive lockouts and requires a special procedure to reset. This ensures the owner will call in a licensed technician to troubleshoot and correct burner problems.
• Power-independent lockout (Power cycling won’t reset from lcokout or latch-up)
• Diagnostic LED’s (Power, call for heat, and lockout/latchup)
• SMC Technology (Safety Monitoring Circuit) Provides two limit relays. Carlin’s Safety Monitoring Circuit monitors the contacts for both relays. Lockout occures if a limit relay contact is found closed when it should be open.)

Bock Commercial Recommended Temperature Range Service Pak - Dual limit (operating limit and manual reset high limit) for direct fired commercial storage water heaters (and similar applications). Includes temperature control, sensor and mounting hardware. Replacement for Carlin Model 90100BL1S. UL Recognized.
