201GAS Commercial Gas Burner

Specs At A Glance

The 201GAS burner converts from propane to natural gas with just an orifice change. No conversion kit needed. Factory packed with combustion control and gas fuel train.
Does not require a refractory liner fires with or without a combustion chamber. Proven in extensive boiler and furnace testing, these burners will meet your needs for residential gas burning applications.

Input

150,000 to 399,000 Btuh

Fuels

Natural Gas or Propane Gas
Maximum Supply Pressure: 14 inches w.c.
Minimum Supply Pressure: 5.0 inches w.c.
Manifold Pressure 3.5 inches w.c.

Control

Carlin 60200FR Microprocessor Control 4 sec. Trial for Ignition (TFI) 1.3 Sec. FFRT Pre-purge and post-purge Serviceman Reset Protection Latch-up after three consecutive lockouts Interrupted Duty Ignition Recyle on Flame Failure

Electrical

Power: 120 vac/60Hz/1-Phase
Current: Approximately 2.5 or 4.4 amps
Limit Circuit Input: 120 vac/60 Hz
Motor: 1/6 or 1/4 HP, 3450 RPM, 60 Hz
Motor Frame: 48 Frame, “N” Flange
Fuel Valve Power: 120 vac/60 Hz

Ignition

Carlin Model 41800 solid state electronic ignition
Ignition Voltage: 9,000 volts

Orifice Selection

Agencies

UL Listed: US & Canada – US per ANSI Z21.17, Canada per CSA 2.7

Commercial Gas Burner Brochure

201GAS Gas Burner Instruction Manual
